2244L 21.5" Open Frame Touchscreen (Discontinued August 2013)
Overview
The Elo Touch Solutions 2244L open-frame LCD touchmonitor with its slim design and narrow outside dimensions gives kiosk integrators an edge in developing the most aesthetically pleasing products. Wide-aspect displays like the Elo 2244L are easier to use and incorporate than traditional open-frame touchmonitors. Wide-screen format displays allow extra content on the screen and are quickly becoming preferred in casino gaming, amusement and entertainment settings and are increasingly popular in public venue environments due to the high-definition cinematic-like experience. Typical applications for the 2244L include: gaming and amusement, information kiosks and self-service, as well as interactive digital signage applications.
State-of-the-art LED backlighting used in the 2244L makes the panel thinner overall as the cold cathode fluorescent lights (CCFL) are replaced with LED lights. LED lights also take less electricity to operate and generate less heat. This leads to the slimmer dimensions of the 2244L that facilitate OEMs and system integrators the flexibility to design aesthetically pleasing and stylish kiosks.
Available with IntelliTouch, IntelliTouch Plus, standard bezel surface acoustic wave, as well as IntelliTouch Zero-Bezel SAW and IntelliTouch Pro projected capacitive touchscreen technology for a true flat look,, the 2244L provides stable "drift-free" operation with outstanding image clarity, resolution, and light transmission - for an accurate touch response and vivid images. Projected capacitive provides a durable, zero-bezel, glass-to-edge surface with multi-touch, while surface acoustic wave is the optical standard of touch and widely used in kiosk and gaming applications. Both are pure glass constructions to deliver a clear, bright and long-lasting performance and it also makes the touchscreens scratch-resistant. It is nearly impossible to physically "wear out" these touchscreens.
Features
- Slimmer dimensions enables thinner, artistic enclosure designs
- Multi-touch, dual-touch and single touch options available
- High definition LCD display offers ultimate HD interactivity, clarity and resolution
- Portrait and landscape mode possible
- IntelliTouch Pro projected capacitive passes ball-drop impact testing to IK07 and UL 60950 standards and offers four touch points (HID)
- Viewing angle of 178°(h) × 178°(v), wider than most 22” touchmonitors, allows colors to remain sharp and graphics to retain their integrity in both portrait and landscape modes
- 16:9 aspect ratio and bright 250 nits panel for a larger display surface and bright vivid images
- LED backlighting allows for state-of-the-art slim design while reducing power consumption
- Optimized for use in high-traffic environments
- Three year warranty
Presupuesto
-
Técnico
Número(s) de Parte(s)
APR (Antiglare, Worldwide) - E738068
Color del empaque
Negro
Tecnología y capacidad táctil
Reconocimiento Acústico de Pulso - Solo Toque
Interface táctile
USB
Tamaño de la diagonal
21.5'' diagonal, matriz activa TFT LCD (LED)
Pantalla en pantalla (OSD)
Controls: Menu, Up, Down, Select
Settings: Brightness, Contrast, Clock, Phase, H-position, V-position, Auto-Adjust, Aspect Ratio, Sharpness, Color Temperature, OSD Timeout, OSD Language, OSD H-Position, OSD V-Position, Recall Defaults, Video Source
Languages: English, French, Italian, German, Spanish, Simplified Chinese, Traditional Chinese, Japanese
Lockouts: OSD, Power
Accessible through switches on the unit's tethered OSD Control Box.Relación de aspecto
16:9
Área activa
18.7" x 10.5" / 475 mm x 267 mm
Resolución
1920x1080
Otras resoluciones disponibles
640x480 60Hz
720x576 50Hz
800x600 56, 60Hz
1024x768 60Hz
1280x720 50, 0Hz
1280x960 60Hz
1280x1024 60Hz
1366x768 60Hz
1440x900 60Hz
1680x1050 60Hz
1920x1080 50, 60HzÁngulo de visión
Horizontal: ±89° or 178° total / Vertical: ±89° or 178° total
Cantidad de colores
16.7 millones
Brillo (tipico)
LCD panel: 250 nits
Tiempo total de respuesta (tipico)
14 msec
Radio de contraste
1000:1
Formato de entrada de video
Analog VGA, DVI-D
Entrada del conector para video señal
Analog VGA on Female DE-15 connector; Digital on Female DVI-D connector
Fuente de alimentación
External DC - Optional power brick (sold separately)
Conector de entrada de energía (Monitor)
Type: DC Barrel Jack
Barrel inner diameter: 6.4mm (+/- 0.3mm)
Pin outer diameter: 2.0mm (+0.0 -0.1mm)
Input voltage range: +12VDC ±5%Conector de energía (Power brick)
Type: IEC 60320 C14
Adapter input voltage range: 100-240VAC, 50/60HzVoltaje de entrada
+12VDC ±5%
Conector de entrada de audio
DC Barrel Jack
Frecuencia de entrada
Horizontal: 31.5-80 kHz
Vertical: 50-75 HzConsumo de energía (típico)
ON (monitor only): 26W
ON (monitor + AC/DC adapter at 230V/50Hz): 39W
SLEEP (monitor + AC/DC adapter at 230V/50Hz): 1.5W
OFF (monitor + AC/DC adapter at 230V/50Hz): 1.0WDimensiones
Please reference the dimensional drawing
Dimensiones de la caja de envio
7.87" x 16.93" x 24.41" / 200 mm x 430 mm x 620 mm
Peso sin empaque
10.6 lbs / 4.8 kg
Peso con empaque
15.3 lbs / 7.0 kg
Temperatura de operación
0°C to 40°C / 32°F to 104°F
Temperatura de almacenamiento
-20°C to 60°C / -4°F to 140°F
Humedad
Operating: 20%-80% Storage: 10%-90%
MTBF - Tiempo medido entre fallos (medida de confiabilidad de un dispositivo o sistema)
50.000 horas demostradas
Garantía
3 años
Aprobaciones y declaraciones reglamentarias
S-Mark, C-Tick, cUL, IC, CCC, CE, VCCI, KCC, Mexico CoC, Taiwan BSMI, UL, FCC, International CB
RoHS, China RoHS, WEEE, IMERCOpciones de montaje
VESA 4-hole 100mm mounting interface on rear of unit
2-hole mounting interface on all 4 sides
See dimensional drawings for detailsOpciones /Periféricos / Ascensos
OSD remoto (RJ45) - Elo N/P: E483757
Kit de cable de repuesto - Elo N/P: E378229
Banco de alimentación y cable para América del Norte - Elo N/P: E005277
Banco de alimentación y cable para Europa y Corea - Elo N/P: E571601
Banco de alimentación y cable para Reino Unido - Elo N/P: E180092
Banco de alimentación y cable para China - Elo N/P: E558862
Banco de alimentación y cable para Taiwán - Elo N/P: E818655
Banco de alimentación y cable para Japón - Elo N/P: E182546
Banco de alimentación y cable para Argentina - Elo N/P: E887099
Lápiz IntelliTouch - Elo N/P: D82064-000
Soporte de montaje en bastidor de 22 pulgadas Elo - Elo N/P: E462672
Bisel de montaje frontal de 22 pulgadas de ancho Elo - Elo N/P: E668194
Soporte en L de 22 pulgadas Elo - Elo N/P: E530432Pluma Stylus IntelliTouch Opcional
Stylus pen with rubber tip, designed specifically for use with IntelliTouch surface wave touch technology. Part number D82064-000, available at additional cost
Recursos
(23)
-
Additional Support Resources
-
Collateral
Hoja de especificaciones
-
Drawings and Certificates
-
User Guides
Guía del usuario en inglés
Guía del usuario en francés
Guía del Usuario Italiano
Guía del usuario alemán
Guía del Usuario Español
Guía del usuario del chino simplificado
Guía del usuario del chino tradicional
Guía del usuario japonés
Guía del usuario coreano
Guía de Usuario Ruso
Guía de instalación rápida
